Electronic Circuit Design

From concept to final product, PNC Inc. is with you every step of the way. We provide circuit design services for the development of conceptual circuits, optimization and the selecting of appropriate components. We provide analog as well as digital solutions from standalone modules to system level.

Services

  • Concept to circuit topology
  • Circuit simulation
  • Circuit optimization
  • Worst case analysis
  • Thermal analysis

Areas

  • Signal conditioning
  • SMPS
  • Filtering
  • Feedback loop control (PID)
  • Sensors

Expertise

  • Processor - 8/16/32 bit, PIC, 8051, ARM, MIPS, DSP
  • I/O - EEPROM, MMC/SD, SPI,I2C, NOR, NAND, SRAM, SDRAM, DDR
  • High speed serial - RS-485, Ethernet, PCIe, USB
  • Analog - Audio, Video, ZigBee, Bluetooth, Wi-Fi(802.11 a/b/c)

Deliverables

  • Schematic, Simulation
  • Optimized BOM, PCB files, Gerber & software
  • User manuals

Examples

Capabilities & Tools

  • OrCAD Capture & pSpice
  • Mentor Graphics PADS/Hyperlynx
  • Cadence Allegro
  • COMSOL
  • MATLAB

Links

Quote Request

Download PNC Brochure

Quick contact

Quick contact

Printed Circuit Boards

PNC Inc. offers every solution in the PCB arena. This includes design, fabrication, assembly and a number of value-added services. With these capabilities and our facilities around the country, we are able to provide quick-turn prototypes and large-scale production all under the same roof. We pride ourselves on constant improvement and invest millions each year into making sure we have the latest technology to make our processes as efficient as possible.

Read More

PNC Online
Phone: (973) 284-1600
Email: sales[at]pnconline[dot]com
